A sound reinforcement system is the combination of microphones, signal processors, amplifiers, and loudspeakers in enclosures all controlled by a mixing console that makes live or pre-recorded sounds louder and may also distribute those sounds to a larger or more distant audience. In many situations, a sound reinforcement system is also used to enhance or alter the sound of the sources on the stage, typically by using electronic effects, such as reverb, as opposed to simply amplifying the sources unaltered.
A sound reinforcement system for a rock concert in a stadium may be very complex, including hundreds of microphones, complex live sound mixing and signal processing systems, tens of thousands of watts of amplifier power, and multiple loudspeaker arrays, all overseen by a team of audio engineers and technicians. On the other hand, a sound reinforcement system can be as simple as a small public address (PA) system, consisting of, for example, a single microphone connected to a 100 watt amplified loudspeaker for a singer-guitarist playing in a small coffeehouse. In both cases, these systems reinforce sound to make it louder or distribute it to a wider audience.
Some audio engineers and others in the professional audio industry disagree over whether these audio systems should be called sound reinforcement (SR) systems or PA systems. Distinguishing between the two terms by technology and capability is common, while others distinguish by intended use (e.g., SR systems are for live event support and PA systems are for reproduction of speech and recorded music in buildings and institutions). In some regions or markets, the distinction between the two terms is important, though the terms are considered interchangeable in many professional circles.
Maps, Directions, and Place Reviews
Basic concept
A typical sound reinforcement system consists of; input transducers (e.g., microphones), which convert sound energy such as a person singing into an electric signal, signal processors which alter the signal characteristics (e.g., equalizers that adjust the bass and treble, compressors that reduce signal peaks, etc.), amplifiers, which produce a powerful version of the resulting signal that can drive a loudspeaker and output transducers (e.g., loudspeakers in speaker cabinets), which convert the signal back into sound energy (the sound heard by the audience and the performers). These primary parts involve varying numbers of individual components to achieve the desired goal of reinforcing and clarifying the sound to the audience, performers, or other individuals.
Signal path
Sound reinforcement in a large format system typically involves a signal path that starts with the signal inputs, which may be instrument pickups (on an electric guitar or electric bass) or a microphone that a vocalist is singing into or a microphone placed in front of an instrument or guitar amplifier. These signal inputs are plugged into the input jacks of a thick multicore cable (often called a snake). The snake then delivers the signals of all of the inputs to one or more mixing consoles.
In a coffeehouse or small nightclub, the snake may be only routed to a single mixing console, which an audio engineer will use to adjust the sound and volume of the onstage vocals and instruments that the audience hears through the main speakers and adjust the volume of the monitor speakers that are aimed at the performers.
Mid- to large-size performing venues typically route the onstage signals to two mixing consoles: the front of house (FOH), and the stage monitor system, which is often a second mixer at the side of the stage. In these cases, at least two audio engineers are required; one to do the main mix for the audience at FOH and another to do the monitor mix for the performers on stage.
Once the signal arrives at an input on a mixing console, this signal can be adjusted in many ways by the sound engineer. A signal can be equalized (e.g., by adjusting the bass or treble of the sound), compressed (to avoid unwanted signal peaks), or panned (that is sent to the left or right speakers). The signal may also be routed into an external effects processor, such as a reverb effect, which outputs a wet (effected) version of the signal, which is typically mixed in varying amounts with the dry (effect-free) signal. Many electronic effects units are used in sound reinforcement systems, including digital delay and reverb. Some concerts use pitch correction effects (e.g., AutoTune), which electronically correct any out-of-tune singing.
Mixing consoles also have additional sends, also referred to as auxes or aux sends (an abbreviation for "auxiliary send"), on each input channel so that a different mix can be created and sent elsewhere for another purpose. One usage for aux sends is to create a mix of the vocal and instrument signals for the monitor mix (this is what the onstage singers and musicians hear from their monitor speakers or in-ear monitors). Another use of an aux send is to select varying amounts of certain channels (via the aux send knobs on each channel), and then route these signals to an effects processor. A common example of the second use of aux sends is to send all of the vocal signals from a rock band through a reverb effect. While reverb is usually added to vocals in the main mix, it is not usually added to electric bass and other rhythm section instruments.
The processed input signals are then mixed to the master faders on the console. The next step in the signal path generally depends on the size of the system in place. In smaller systems, the main outputs are often sent to an additional equalizer, or directly to a power amplifier, with one or more loudspeakers (typically two, one on each side of the stage in smaller venues, or a large number in big venues) that are connected to that amplifier. In large-format systems, the signal is typically first routed through an equalizer then to a crossover. A crossover splits the signal into multiple frequency bands with each band being sent to separate amplifiers and speaker enclosures for low, middle, and high-frequency signals. Low-frequency signals are sent to amplifiers and then to subwoofers, and middle and high-frequency sounds are typically sent to amplifiers which power full-range speaker cabinets. Using a crossover to separate the sound into low, middle and high frequencies can lead to a "cleaner", clearer sound (see bi-amplification) than routing all of the frequencies through a single full-range speaker system. Nevertheless, many small venues still use a single full-range speaker system, as it is easier to set up and less expensive.
Setting Up Speakers Video
System components
Input transducers
Many types of input transducers can be found in a sound reinforcement system, with microphones being the most commonly used input device. Microphones can be classified according to their method of transduction, pickup (or polar) pattern or their functional application. Most microphones used in sound reinforcement are either dynamic or condenser microphones. One type of directional mics, called cardioid mics, are widely used in live sound, because they reduce pickup from the side and rear, helping to avoid unwanted feedback "howls" or "screams" from the monitors.
Microphones used for sound reinforcement are positioned and mounted in many ways, including base-weighted upright stands, podium mounts, tie-clips, instrument mounts, and headset mounts. Microphones on stands are also placed in front of instruments and guitar amplifiers to pick up the sound. Headset mounted and tie-clip mounted microphones are often used with wireless transmission to allow performers or speakers to move freely. Early adopters of headset mounted microphones technology included country singer Garth Brooks, Kate Bush, and Madonna.
There are many other types of input transducers which may be used occasionally, including magnetic pickups used in electric guitars and electric basses, which are plugged first into a DI box and then into the snake, contact microphones used on stringed instruments, and pianos and phonograph pickups (cartridges) used in record players. As well, some electronic instruments such as synthesizers can have their output signal routed to the mixing console.
In the 1980s, wireless technology tended to be only used by touring professionals, but in the 2010s, wireless mics and instrument transmitters has become popular in sound reinforcement. Wireless systems are typically used for electric guitar, bass, and handheld microphones. This lets performers move about the stage during the show or even go out into the audience without the worry of tripping over or disconnecting the cable.
Mixing consoles
Mixing consoles are the heart of a sound reinforcement system. This is where the sound engineer can adjust the volume and tone of each input, whether it is a vocalist's microphone or the signal from an electric bass, and mix, equalize and add effects to these sound sources. Doing the mixing for a live show requires a mix of technical and artistic/creative skills. A sound engineer needs to have an expert knowledge of speaker and amplifier set-up and other technologies. As well, a sound engineer has to have a good "ear" for what the music should sound like in order to create a good mix and use effects units appropriately. Every genre and style of music has different approaches to live sound mixing. The mixing approach for a hard rock band is very different from the mixing approach for a bluegrass music show; a hard rock show will typically have powerful subwoofer cabinets to create a "heavy", loud onstage sound. A bluegrass show will typically have a more "acoustic" or "natural" sound, in which the PA system simply reinforces the volume of the more quiet instruments.
Multiple consoles can be used for different applications in a single sound reinforcement system. The Front of House (FOH) mixing console must be located where the operator can see the action on stage and hear the output of the loudspeaker system. Some venues with permanently installed systems such as religious facilities and theaters place the mixing console within an enclosed booth, but this approach is more common for broadcast and recording applications. This is far less common in live sound reproduction, since the engineer performs best when he can hear what the audience hears.
Large music productions often use a separate stage monitor mixing console which is dedicated to creating mixes for the performers' on-stage or in-ear monitors. These consoles are typically placed at the side of the stage so that the operator can communicate with the performers on stage. In cases where performers have to play at a venue that does not have a monitor engineer near the stage, the monitor mixing is done by the FOH engineer from the FOH console, which is located amongst the audience or at the back of the hall. This arrangement can be problematic because the performers end up having to request changes to the monitor mixes with "...hand signals and clever cryptic phrases" which may be misunderstood. The engineer also cannot hear the changes that he is applying to the monitors on stage, often resulting in a reduction of the quality of the onstage monitor mix.
Signal processors
In the 2010s, small PA systems for venues such as bars and clubs are now available with features that were formerly only available on professional-level equipment, such as digital reverb effects, graphic equalizers, and, in some models, feedback prevention circuits which electronically sense and prevent feedback "howls" before they become a problem. Digital effects units may offer multiple pre-set and variable reverb, echo and related effects. Digital loudspeaker management systems offer sound engineers digital delay (to ensure speakers are in sync with each other), limiting, crossover functions, EQ filters, compression and other functions in a single rack-mountable unit. In previous decades, sound engineers typically had to transport a substantial number of rack-mounted analog effects unit devices to accomplish these tasks.
Equalizers
Equalizers are electronic devices that allow audio engineers to control the tone and frequencies of the sound in a channel, group (e.g., all the mics on a drumkit) or an entire stage's mix. The bass and treble controls on a home stereo are a simple type of equalizer. Equalizers exist in pro sound reinforcement systems in three forms: shelving equalizers (typically for a whole range of bass and treble frequencies), graphic equalizers and parametric equalizers. Graphic equalizers have faders (vertical slide controls) which together resemble a frequency response curve plotted on a graph. The faders can be used to boost or cut specific frequency bands.
Using equalizers, frequencies which are too weak, such as a singer with modest projection in her/his lower register, can be boosted. Frequencies which are too loud, such as a "boomy" sounding bass drum, or an overly resonant dreadnought guitar can be cut. Sound reinforcement systems typically use graphic equalizers with one-third octave frequency centers. These are typically used to equalize output signals going to the main loudspeaker system or the monitor speakers on stage. Parametric equalizers are often built into each channel in mixing consoles, typically for the mid-range frequencies. They are also available as separate rackmount units which can be connected to a mixing board. Parametric equalizers typically use knobs and sometimes buttons. The audio engineer can select which frequency band to cut or boost, and then use additional knobs to cut or boost this frequency range. Parametric equalizers first became popular in the 1970s and have remained the program equalizer of choice for many engineers since then.
A high-pass (low-cut) and/or low-pass (high-cut) filter may also be included on equalizers or audio consoles. High-pass (low-cut) and low-pass (high-cut) filters restrict a given channel's bandwidth extremes. Cutting very low frequency sound signals (termed infrasonic, or subsonic, a misnomer) reduces the waste of amplifier power which does not produce audible sound and which moreover can be hard on the low-range speakers. A low-pass filter to cut ultrasonic energy is useful to prevent interference from radio frequencies, lighting control hum, or digital circuitry creeping into the power amplifiers. Such filters are often included with graphic and parametric equalizers to give the audio engineer full control of the frequency range. If their response is steep enough, high-pass filters and low-pass filters function as end-cut filters. A feedback suppressor is an automatically-adjusted band-reject or notch filter which includes a microprocessor to detect the onset of feedback "howls" and direct the filter to suppress the feedback by lowering the gain right at the offending frequency.
Compressors
Compressors are designed to help the audio engineer to manage the dynamic range (loudness) of an audio signal, or a group of audio signals. Prior to the invention of automatic compressors, audio engineers accomplished the same goal by "riding the faders", which mean listening carefully to the mix and lowering the faders of any singer or instrument which was getting too loud. A compressor accomplishes this by reducing the gain of a signal that is above a defined level (the threshold) by a defined amount (the ratio). Without this gain reduction, a signal that gets, say 10% louder as an input, will be 10% louder at the output. With the gain reduced, a signal that gets 10% louder at the input will be perhaps 3% louder at the output. Most compressors available are designed to allow the operator to select a ratio within a range typically between 1:1 and 20:1, with some allowing settings of up to ?:1. A compressor with an infinite ratio is typically referred to as a limiter. The speed that the compressor adjusts the gain of the signal (called the attack) is typically adjustable as is the final output of the device.
Compressor applications vary widely from objective system design criterion to subjective applications determined by variances in program material and engineer preference. Some system design criteria specify limiters for component protection and gain structure control. Artistic signal manipulation is a subjective technique widely utilized by mix engineers to improve clarity or to creatively alter the signal in relation to the program material. An example of artistic compression is the typical heavy compression used on the various components of a modern rock drum kit. The drums are processed to be perceived as sounding more punchy and full.
Noise gates
A noise gate sets a threshold where if it is quieter it will not let the signal pass and if it is louder it opens the gate. A noise gate's function is in a sense the opposite to that of a compressor. Noise gates are useful for microphones which will pick up noise which is not relevant to the program, such as the hum of a miked electric guitar amplifier or the rustling of papers on a minister's lectern. Noise gates are also used to process the microphones placed near the drums of a drum kit in many hard rock and metal bands. Without a noise gate, the microphone for a specific instrument such as the floor tom will also pick up signal from nearby drums or cymbals. With a noise gate, the threshold of sensitivity for each microphone on the drum kit can be set so that only the direct strike and subsequent decay of the drum will be heard, not the nearby sounds.
Effects
Reverberation and delay effects are widely used in sound reinforcement systems to enhance the sound of the mix and create a desired artistic effect. Reverb and delay add a sense of spaciousness to the sound, imitating the sound of a singing voice or instrument in a large, reverberant hall. Many mixing boards designed for live sound include on-board reverb effects. Modulation effects such as flanger, phaser, and chorus are also applied to some instruments. An exciter "livens up" the sound of audio signals by applying dynamic equalization, phase manipulation and harmonic synthesis of typically high frequency signals.
The appropriate type, variation, and level of effects is quite subjective and is often collectively determined by a production's audio engineer, artists, bandleader, music producer, or musical director. Reverb, for example, can give the effect of signal being present in anything from a small room to a massive hall, or even in a space that does not exist in the physical world. The use of reverb often goes unnoticed by the audience, as it often sounds more natural than if the signal was left "dry" (without effects). The use of effects in the reproduction of 2010-era pop music is often in an attempt to mimic the sound of the studio version of the artist's music in a live concert setting. For example, an audio engineer may use an Auto Tune effect to produce unusual vocal sound effects that a singer used on his/her recordings.
Feedback suppressor
A feedback suppressor detects unwanted audio feedback and suppresses it, typically by automatically inserting a notch filter into the signal path of the system, which prevents feedback "howls" from occurring. Audio feedback can create unwanted loud, screaming noises which are disruptive to the performance, and which can damage performers' and audience members' ears and speakers. Audio feedback from microphones occurs when a microphone "hears" the sound it is picking up through the monitor speakers or the main speakers. While microphone audio feedback is almost universally regarded as a negative phenomenon, in hard rock and heavy metal music, electric guitarists purposely create guitar feedback to create unique, sustained sounds with their guitar and guitar amplifier. This type of feedback is sought out by guitarists, so the sound engineer does not try to prevent it.
Power amplifiers
A power amplifier is an electronic device which uses electrical power and circuitry to boost a low-voltage level signal (e.g., the signal from a vocalist's mic) and provides enough electrical power to drive a loudspeaker and produce sound. All speakers, including headphones, require power amplification. Most professional audio amplifiers also provide protection from clipped (overloaded) signals, as a power amplifier pushed into clipping can damage or destroy speakers. Amplifiers also typically provide protection against short circuits across the output, and excessive temperature (e.g., overheating). A limiter is often used to protect loudspeakers and amplifiers from power amp clipping.
Audio engineers select amplifiers that provide enough headroom. "Headroom" refers to the amount by which the signal-handling capabilities of an audio system exceed a designated nominal level. Headroom can be thought of as a safety zone allowing transient audio peaks to exceed the nominal level without damaging the system or the audio signal, e.g., via clipping. Standards bodies differ in their recommendations for nominal level and headroom. When an audio engineer has selected an amplifier (or amplifiers) with enough headroom, this also helps to ensure that the signal will remain clean and undistorted.
Like most sound reinforcement equipment products, professional amplifiers are typically designed to be mounted within standard 19-inch racks. Rack-mounted amps are typically housed in road cases, sturdy plastic protective boxes which prevent damage to the equipment during transportation. Active loudspeakers have internally mounted amplifiers that have been selected by the manufacturer to be a good amplifier for use with the given loudspeaker. Some active loudspeakers also have equalization, crossover and mixing circuitry built in.
Since amplifiers can generate a significant amount of heat, thermal dissipation is an important factor for operators to consider when mounting amplifiers into equipment racks. Many power amplifiers feature internal fans to draw air across their heat sinks. The heat sinks can become clogged with dust, which can adversely affect the cooling capabilities of the amplifier.
In the 1970s and 1980s, most PAs employed heavy Class AB amplifiers. In the late 1990s, power amplifiers in PA applications became lighter, smaller, more powerful, and more efficient, with the increasing use of switching power supplies and Class D amplifiers, which offered significant weight- and space-savings as well as increased efficiency. Often installed in railroad stations, stadia, and airports, Class D amplifiers can run with minimal additional cooling and with higher rack densities, compared to older amplifiers.
Digital loudspeaker management systems (DLMS) that combine digital crossover functions, compression, limiting, and other features in a single unit have become popular since their introduction. They are used to process the mix from the mixing console and route it to the various amplifiers. Systems may include several loudspeakers, each with its own output optimized for a specific range of frequencies (i.e. bass, midrange, and treble). Bi-amplifiication, tri-amplification, or quad-amplification of a sound reinforcement system with the aid of a DLMS results in a more efficient use of amplifier power by sending each amplifier only the frequencies appropriate for its respective loudspeaker. Most DLMS units that are designed for use by non-professionals have calibration and testing functions such as a pink noise generator coupled with a real-time analyzer to allow automated room equalization.
Output transducers
Main loudspeakers
A simple and inexpensive PA loudspeaker may have a single full-range loudspeaker driver, housed in a suitable enclosure. More elaborate, professional-caliber sound reinforcement loudspeakers may incorporate separate drivers to produce low, middle, and high frequency sounds. A crossover network routes the different frequencies to the appropriate drivers. In the 1960s, horn loaded theater loudspeakers and PA speakers were almost always "columns" of multiple drivers mounted in a vertical line within a tall enclosure. The 1970s to early 1980s was a period of innovation in loudspeaker design with many sound reinforcement companies designing their own speakers. The basic designs were based on commonly known designs and the speaker components were commercial speakers.
The areas of innovation were in cabinet design, durability, ease of packing and transport, and ease of setup. This period also saw the introduction of the hanging or "flying" of main loudspeakers at large concerts. During the 1980s the large speaker manufacturers started producing standard products using the innovations of the 1970s. These were mostly smaller two way systems with 12", 15" or double 15" woofers and a high frequency driver attached to a high frequency horn. The 1980s also saw the start of loudspeaker companies focused on the sound reinforcement market. The 1990s saw the introduction of Line arrays, where long vertical arrays of loudspeakers with a smaller cabinet are used to increase efficiency and provide even dispersion and frequency response. This period also saw the introduction of inexpensive molded plastic speaker enclosures mounted on tripod stands. Many feature built-in power amplifiers which made them practical for non-professionals to set up and operate successfully. The sound quality available from these simple 'powered speakers' varies widely depending on the implementation.
Many sound reinforcement loudspeaker systems incorporate protection circuitry, preventing damage from excessive power or operator error. Positive temperature coefficient resistors, specialized current-limiting light bulbs, and circuit-breakers were used alone or in combination to reduce driver failures. During the same period, the professional sound reinforcement industry made the Neutrik Speakon NL4 and NL8 connectors the standard input connectors, replacing 1/4" jacks, XLR connectors, and Cannon multipin connectors which are all limited to a maximum of 15 amps of current. XLR connectors are still the standard input connector on active loudspeaker cabinets.
The three different types of transducers are subwoofers, compression drivers, and tweeters. They all feature the combination of a voicecoil, magnet, cone or diaphragm, and a frame or structure. Loudspeakers have a power rating (in watts) which indicates their maximum power capacity, to help users avoid overpowering them. Thanks to the efforts of the Audio Engineering Society (AES) and the loudspeaker industry group ALMA, power-handling specifications became more trustworthy, although adoption of the EIA-426-B standard is far from universal. Around the mid 1990s trapezoidal-shaped enclosures became popular as this shape allowed many of them to be easily arrayed together.
A number of companies are now making lightweight, portable speaker systems for small venues that route the low-frequency parts of the music (electric bass, bass drum, etc.) to a powered subwoofer. Routing the low-frequency energy to a separate amplifier and subwoofer can substantially improve the bass-response of the system. Also, clarity may be enhanced, because low-frequency sounds take a great deal of power to amplify; with only a single amplifier for the entire sound spectrum, the power-hungry low-frequency sounds can take a disproportionate amount of the sound system's power.
Professional sound reinforcement speaker systems often include dedicated hardware for safely "flying" them above the stage area, to provide more even sound coverage and to maximize sight lines within performance venues.
Monitor loudspeakers
Monitor loudspeakers, also called "foldback" loudspeakers, are speaker cabinets which are used onstage to help performers to hear their singing or playing. As such, monitor speakers are pointed towards a performer or a section of the stage. They are generally sent a different mix of vocals or instruments than the mix that is sent to the main loudspeaker system. Monitor loudspeaker cabinets are often a wedge shape, directing their output upwards towards the performer when set on the floor of the stage. Two-way, dual driver designs with a speaker cone and a horn are common, as monitor loudspeakers need to be smaller to save space on the stage. These loudspeakers typically require less power and volume than the main loudspeaker system, as they only need to provide sound for a few people who are in relatively close proximity to the loudspeaker. Some manufacturers have designed loudspeakers for use either as a component of a small PA system or as a monitor loudspeaker. In the 2000s, a number of manufacturers produced powered monitor speakers, which contain an integrated amplifier.
Using monitor speakers instead of in ear monitors typically results in an increase of stage volume, which can lead to more feedback issues and progressive hearing damage for the performers in front of them. The clarity of the mix for the performer on stage is also typically not as clear as they hear more extraneous noise from around them. The use of monitor loudspeakers, active (with an integrated amplifier) or passive, requires more cabling and gear on stage, resulting in an even more cluttered stage. These factors, amongst others, have led to the increasing popularity of in-ear monitors.
In-ear monitors
In-ear monitors are headphones that have been designed for use as monitors by a live performer. They are either of a "universal fit" or "custom fit" design. The universal fit in ear monitors feature rubber or foam tips that can be inserted into virtually anybody's ear. Custom fit in ear monitors are created from an impression of the users ear that has been made by an audiologist. In-ear monitors are almost always used in conjunction with a wireless transmitting system, allowing the performer to freely move about the stage while maintaining their monitor mix.
In-ear monitors offer considerable isolation for the performer using them, meaning that the monitor engineer can craft a much more accurate and clear mix for the performer. With in-ear monitors, each performer can be sent their own customized mix; although this was also the case with monitor speakers, the in-ear monitors of one performer cannot be heard by the other musicians. A downside of this isolation is that the performer cannot hear the crowd or the comments other performers on stage that do not have microphones (e.g., if the bass player wishes to communicate to the drummer). This has been remedied by larger productions by setting up a pair of microphones on each side of the stage facing the audience that are mixed into the in-ear monitor sends.
Since their introduction in the mid-1980s, in-ear monitors have grown to be the most popular monitoring choice for large touring acts. The reduction or elimination of loudspeakers other than instrument amplifiers on stage has allowed for cleaner and less problematic mixing situations for both the front of house and monitor engineers. Audio feedback is greatly reduced and there is less sound reflecting off the back wall of the stage out into the audience, which affects the clarity of the mix the front of house engineer is attempting to create.
Applications
Sound reinforcement systems are used in a broad range of different settings, each of which poses different challenges.
Rental systems
Audio visual (AV) rental systems have to be able to withstand heavy use, and even abuse from renters. For this reason, rental companies tend to own speaker cabinets which are heavily braced and protected with steel corners, and electronic equipment such as power amplifiers or effects are often mounted into protective road cases. As well, rental companies tend to select gear which has electronic protection features, such as speaker-protection circuitry and amplifier limiters.
As well, rental systems for non-professionals need to be easy to use and set up, and they must be easy to repair and maintain for the renting company. From this perspective, speaker cabinets need to have easy-to-access horns, speakers, and crossover circuitry, so that repairs or replacements can be made. Some rental companies often rent powered amplifier-mixers, mixers with onboard effects, and powered subwoofers for use by non-professionals, which are easier to set up and use.
Many touring acts and large venue corporate events will rent large sound reinforcement systems that typically include one or more audio engineers on staff with the renting company. In the case of rental systems for tours, there are typically several audio engineers and technicians from the rental company that tour with the band to set up and calibrate the equipment. The individual that mixes the band is often selected and provided by the band, as they have become familiar with the various aspects of the show and have worked with the act to establish a general idea of how they want the show to sound. The mixing engineer for an act sometimes also happens to be on staff with the rental company selected to provide the gear for the tour.
Live music clubs and dance events
Setting up sound reinforcement for live music clubs and dance events often poses unique challenges, because there is such a large variety of venues which are used as clubs, ranging from former warehouses or music theaters to small restaurants or basement pubs with concrete walls. Dance events may be held in huge warehouses, aircraft hangars or outdoor spaces. In some cases, clubs are housed in multi-story venues with balconies or in "L"-shaped rooms, which makes it hard to get a consistent sound for all audience members. The solution is to use fill-in speakers to obtain good coverage, using a delay to ensure that the audience does not hear the same sound at different times.
The number of subwoofer speaker cabinets and power amplifiers dedicated to low-frequency sounds used in a club depends on the type of club, the genres of music played there (live or via a DJ), and the size of the venue. A small coffeehouse where traditional folk, bluegrass or jazz groups are the main performers may have no subwoofers, and instead rely on the full-range main PA speakers to reproduce bass sounds. On the other hand, a club where hard rock or heavy metal music bands play or a nightclub where house music DJs play dance music may have multiple large 18" subwoofers in big cabinets and powerful amplifiers dedicated for subwoofers, as these genres and music styles typically use powerful, deep bass sound.
Another challenge with designing sound systems for live music clubs is that the sound system may need to be used for both prerecorded music played by DJs and live music. If the sound system is optimized for prerecorded DJ music, then it will not provide the appropriate sound qualities (or mixing equipment and monitoring equipment) needed for live music, and vice versa. A club system designed for DJs needs a DJ mixer and space for record players. Clubs tend to focus on either live music or DJ shows. However, clubs which feature both types of shows may face challenges providing the desired equipment and set-up for both uses. In contrast, a live music club needs a mixing board designed for live sound, an onstage monitor system, and a multicore "snake" cable running from the stage to the mixer. Lastly, live music clubs can be a hostile environment for sound gear, in that the air may be hot, humid, and smoky; in some clubs, keeping racks of power amplifiers cool may be a challenge. Often an air conditioned room just for the amplifiers is utilised.
Church sound
Designing systems in churches and similar religious facilities often poses a challenge, because the speakers may have to be unobtrusive to blend in with antique woodwork and stonework. In some cases, audio designers have designed custom-painted speaker cabinets so that the speakers will blend in with the church architecture. Some church facilities, such as sanctuaries or chapels are long rooms with low ceilings, which means that additional fill-in speakers are needed throughout the room to give good coverage. An additional challenge with church SR systems is that, once installed, they are often operated by amateur volunteers from the congregation, which means that they must be easy to operate and troubleshoot.
Some mixing consoles designed for houses of worship have automatic mixers, which turn down unused channels to reduce noise, and automatic feedback elimination circuits which detect and notch out frequencies that are feeding back. These features may also be available in multi-function consoles used in convention facilities and multi-purpose venues.
Touring systems
Touring sound systems have to be powerful and versatile enough to cover many different halls and venues, and they are available many different sizes and shapes. Touring systems range from mid-sized systems for bands playing nightclub and other mid-sized venues to large systems for groups playing stadiums, arenas and outdoor festivals. They also need to use "field-replaceable" components such as speakers, horns, and fuses, which are easily accessible for repairs during a tour. Tour sound systems are often designed with substantial redundancy features, so that in the event of equipment failure or amplifier overheating, the system will continue to function. Touring systems for bands performing for crowds of a few thousand people and up are typically set up and operated by a team of technicians and engineers who travel with the performers to every show.
Mainstream bands that are going to perform in mid- to large-sized venues during their tour schedule one to two weeks of technical rehearsal with the entire concert system and production staff, including audio engineers, at hand. This allows the audio and lighting engineers to become familiar with the show and establish presets on their digital equipment (e.g., digital mixers) for each part of the show, if needed. Many modern musical groups work with their Front of House and monitor mixing engineers during this time to establish what their general idea is of how the show and mix should sound, both for themselves on stage and for the audience.
This often involves programming different effects and signal processing for use on specific songs, to make the songs sound somewhat similar to the studio versions. To manage a show with a lot of effects changes, the mixing engineers for the show often choose to use a digital mixing console so that they can save and automatically recall these many settings in between each song. This time is also used by the system technicians to get familiar with the specific combination of gear that is going to be used on the tour and how it acoustically responds during the show. These technicians remain busy during the show, making sure the SR system is operating properly and that the system is tuned correctly, as the acoustic response of a room or venue will respond differently throughout the day depending on the temperature, humidity, and number of people in the room or space.
"Weekend band" PA systems are a niche market for small, powerful touring SR gear. Weekend bands need systems that are small enough to fit into a minivan or a car trunk, and yet powerful enough to give adequate and even sound dispersion and vocal intelligibility in a noisy club or bar. As well, the systems need to be easy and quick to set up. Sound reinforcement companies have responded to this demand by offering equipment that fulfills multiple roles, such as powered mixers (a mixer with an integrated power amplifier and effects) and powered subwoofers (a subwoofer with an integrated power amplifier and crossover). These products minimize the number of wiring connections that bands have to make to set up the system and they take less time to set up. Some subwoofers have metal speaker mount holes built into the top, so that they can double as a base for the stand-mounted full-range PA speaker cabinets.
Live theater
Sound for live theater, operatic theater, and other dramatic applications may pose problems similar to those of churches, in cases where a theater is an old heritage building where speakers and wiring may have to blend in with woodwork. The need for clear sight lines in some theaters may make the use of regular speaker cabinets unacceptable; instead, slim, low-profile speakers are often used instead.
In live theater and drama, performers move around onstage, which means that wireless microphones may have to be used. Wireless microphones need to be set up and maintained properly, to avoid interference and reception problems.
Some of the higher budget theater shows and musicals are mixed in surround sound live, often with the show's sound operator triggering sound effects that are being mixed with music and dialogue by the show's mixing engineer. These systems are usually much more extensive to design, typically involving a separate sets of speakers for different zones in the theater.
Classical music and opera
A subtle type of sound reinforcement called acoustic enhancement is used in some concert halls where classical music such as symphonies and opera is performed. Acoustic enhancement systems help give a more even sound in the hall and prevent "dead spots" in the audience seating area by "...augment[ing] a hall's intrinsic acoustic characteristics." The systems use "...an array of microphones connected to a computer [which is] connected to an array of loudspeakers." However, as concertgoers have become aware of the use of these systems, debates have arisen, because "...purists maintain that the natural acoustic sound of [Classical] voices [or] instruments in a given hall should not be altered."
Kai Harada's article Opera's Dirty Little Secret states that opera houses have begun using electronic acoustic enhancement systems "...to compensate for flaws in a venue's acoustical architecture." Despite the uproar that has arisen amongst operagoers, Harada points out that none of the opera houses using acoustic enhancement systems "...use traditional, Broadway-style sound reinforcement, in which most if not all singers are equipped with radio microphones mixed to a series of unsightly loudspeakers scattered throughout the theatre." Instead, most opera houses use the sound reinforcement system for acoustic enhancement, and for subtle boosting of offstage voices, onstage dialogue, and sound effects (e.g., church bells in Tosca or thunder in Wagnerian operas).
Acoustic enhancement systems include LARES (Lexicon Acoustic Reinforcement and Enhancement System) and SIAP, the System for Improved Acoustic Performance. These systems use microphones, computer processing "with delay, phase, and frequency-response changes", and then send the signal "... to a large number of loudspeakers placed in extremities of the performance venue." Another acoustic enhancement system, VRAS (Variable Room Acoustics System) uses "...different algorithms based on microphones placed around the room." The Deutsche Staatsoper in Berlin and the Hummingbird Centre in Toronto use a LARES system. The Ahmanson Theatre in Los Angeles, the Royal National Theatre in London, and the Vivian Beaumont Theater in New York City use the SIAP system.
Lecture halls and conference rooms
Lecture halls and conference rooms pose the challenge of reproducing speech clearly to a large hall, which may have reflective, echo-producing surfaces. One issue with reproducing speech is that the microphone used to pick up the sound of an individual's voice may also pick up unwanted sounds, such as the rustling of papers on a podium. A more tightly directional microphone may help to reduce unwanted background noises.
Another challenge with doing live sound for individuals who are speaking at a conference is that, in comparison with professional singers, individuals who are invited to speak at a forum may not be familiar with how microphones work. Some individuals may accidentally point the microphone towards a speaker or monitor speaker, which may cause audio feedback "howls". In some cases, when an individual who is speaking does not speak enough directly into the microphone, the audio engineer may ask the individual to wear a lavaliere microphone, which can be clipped onto a lapel.
In some conferences, sound engineers have to provide microphones for a large number of people who are speaking, in the case of a panel conference or debate. In some cases, automatic mixers are used to control the levels of the microphones, and turn off the channels for microphones which are not being spoken into, to reduce unwanted background noise and reduce the likelihood of feedback.
Sports sound systems
Systems for outdoor sports facilities and ice rinks often have to deal with substantial echo, which can make speech unintelligible. Sports and recreational sound systems often face environmental challenges as well, such as the need for weather-proof outdoor speakers in outdoor stadiums and humidity- and splash-resistant speakers in swimming pools. Another challenge with sports sound reinforcement setups is that in many arenas and stadiums, the spectators are on all four sides of the playing field. This requires 360 degree sound coverage. This is very different from the norm with music festivals and music halls, where the musicians are on stage and the audience is seated in front of the stage.
Setting up and testing
Large-scale sound reinforcement systems are designed, installed, and operated by audio engineers and audio technicians. During the design phase of a newly constructed venue, audio engineers work with architects and contractors, to ensure that the proposed design will accommodate the speakers and provide an appropriate space for sound technicians and the racks of audio equipment. Sound engineers will also provide advice on which audio components would best suit the space and its intended use, and on the correct placement and installation of these components. During the installation phase, sound engineers ensure that high-power electrical components are safely installed and connected and that ceiling or wall mounted speakers are properly mounted (or "flown") onto rigging. When the sound reinforcement components are installed, the sound engineers test and calibrate the system so that its sound production will be even across the frequency spectrum.
System testing
A sound reinforcement system should be able to accurately reproduce a signal from its input, through any processing, to its output without any coloration or distortion. However, due to inconsistencies in venue sizes, shapes, building materials, and even crowd densities, this is not always possible without prior calibration of the system. This can be done in one of several ways. The oldest method of system calibration involves a set of healthy ears, test program material (i.e. music or speech), a graphic equalizer, and last but certainly not least, a familiarity with the proper (or desired) frequency response. One must then listen to the program material through the system, take note of any noticeable frequency changes or resonances, and subtly correct them using the equalizer. Experienced engineers typically use a specific playlist of music that they have become very familiar with every time they calibrate a new system. This "by ear" process is still done by many engineers, even when analysis equipment is used, as a final check of how the system sounds with music or speech playing through the system.
Another method of manual calibration requires a pair of high-quality headphones patched into the input signal before any processing (such as the pre-fade-listen of the test program input channel of the mixing console, or the headphone output of the CD player or tape deck). One can then use this direct signal as a near-perfect reference with which to find any differences in frequency response. This method may not be perfect, but it can be very helpful with limited resources or time, such as using pre-show music to correct for the changes in response caused by the arrival of a crowd. Because this is still a very subjective method of calibration, and because the human ear is so dynamic in its own response, the program material used for testing should be as similar as possible to that for which the system is being used.
Since the development of digital signal processing (DSP), there have been many pieces of equipment and computer software designed to shift the bulk of the work of system calibration from human auditory interpretation to software algorithms that run on microprocessors. One tool for calibrating a sound system using either DSP or Analog Signal Processing is a Real Time Analyzer (RTA). This tool is usually used by piping pink noise into the system and measuring the result with a special calibrated microphone connected to the RTA. Using this information, the system can be adjusted to help achieve the desired response. The displayed response from the RTA mic cannot be taken as a perfect representation of the room as the analysis will be different, sometimes drastically, when the mic is placed in different position in front of the system.
More recently, sound engineers have seen the introduction of dual "fft" (fast-fourier transform) based audio analysis software which allows an engineer to view not only frequency vs. amplitude (pitch vs. volume) information that an RTA provides, but also to see the same signals (sounds) in the time domain. This provides the engineer with much more meaningful data than an rta alone. Also, dual fft analysis allows one to compare the source signal with the output signal and view the difference. This is a very fast way to calibrate a system to sound as close as possible to the original source material. As with any such measurement tool, it must always be verified using actual human ears. Some DSP system processing devices have been designed for use by non-professionals that automatically make adjustments in the system EQ based upon what is being read from the RTA mic. These are practically never used by professionals, as they almost never calibrate the system as well as a professional audio engineer can manually.
Equipment supply stores
Professional audio stores sell microphones, speaker enclosures, monitor speakers, mixing boards, rack-mounted effects units and related equipment designed for use by audio engineers and technicians. Professional audio stores are also called "pro audio stores", "pro sound stores", "sound reinforcement" companies, "PA system companies" or "audio-visual companies", with the latter name being used when a store supplies a significant amount of video equipment for events, such as video projectors and screens. Stores often use the word "professional" or "pro" in their name or the description of their store, to differentiate their stores from consumer electronics stores, which sell consumer-grade loudspeakers, home cinema equipment, and amplifiers, which are designed for private, in-home use.
