In computing and video gaming, a docking station or port replicator or dock provides a simplified way of "plugging-in" an electronic device such as the tablet-like hybrid video game console, the Nintendo Switch and laptop computer to common peripherals. Because a wide range of dockable devices--from mobile telephones to wireless mice--have different connectors, power signaling, and uses, docks are not standardized and are therefore often designed with a specific make and model of a device in mind.
A dock can allow some laptop computers to become a substitute for a desktop computer, without sacrificing the mobile computing functionality of the machine. Portable computers can dock and undock hot, cold or standby, depending on the capabilities of the system. In a cold dock or undock, one completely shuts the computer down before docking/undocking. In a hot dock or undock, the computer remains running when docked/undocked. Standby docking or undocking, an intermediate style used in some designs, allows the computer to be docked/undocked while powered on, but requires that it be placed into a sleep mode prior to docking/undocking.
Maps, Directions, and Place Reviews
Types
Docking stations can be broadly split up into four basic varieties.
Port replicator
Port replicators (also called passthroughs) are functionally and logically identical to a bundle of extension cables, except that they are plugged in and unplugged together through the docking port. Some also include electrical adaptors to change from one pinout to another (e.g., Micro-DVI to normal DVI connector.)
Breakout dock
A breakout dock is conceptually a breakout box in the form of a dock. It is an extension to a typical port replicator in that it not only replicates existing ports already on the computer, but also offers additional ports. Modern computers most often accomplish this by using a special, often proprietary, connector that consolidates the signals from many concealed traces from onboard external buses into one connector. As such, the dock can offer a greater number of ports than is physically present on the computer. This allows the basic unit to have fewer physical ports while still allowing users a way to access to the full range of features of its motherboard.
Most companies that produce laptops with such breakout ports also offer simpler adapters that grant access to one or two of the buses consolidated in them at a time.
Docking Port by Eden
Similar to a breakout device, some docking stations produce multiple connections from one port, only instead of extracting them from internal chipsets, they create them inside the dock using converters. They are functionally identical to a hub with various converters plugged in. Typically USB- or Thunderbolt-based, they incorporate a range of converters such as USB display adapters or a full external GPU, audio chipsets, NICs, storage enclosures, modems and memory card readers even PCI Express card slots connected through an internal USB hub or PCI Express bridge to give the host computer access to extra connections it did not previously possess. Simpler "docking stations" consist of nothing more than a hub inside a stand.
As they tend to use non-proprietary connections, converter docks are usually vendor neutral and supplied by third parties.
Speakers Docking Station Video
Computer stands
Computer stands are sometimes also called docking stations, although they do not connect to the computer in any way. They are an inert accessory designed merely to physically support a computer that is placed on it, typically to raise its screen up to a more ergonomic height, provide cooling, or just to conserve desk space.
In video gaming/Use in video game consoles
The Nintendo Switch is a tablet-like hybrid video game console that has a docking station where the main Switch unit can be placed to charge it, or to play on a television.
Mobile docking stations
Mobile docking stations, also referred to as vehicle mounts, provide stable platforms for notebook, laptop and tablet operation in vehicles. Many industries have adopted mobile computing and hence operators wish to have their vehicles fully equipped as mobile field-offices, commonly referred to as mobile offices. As of 2015 organizations use mobile docking stations in sectors such as (for example): law-enforcement, electricity, telecommunications, the military, emergency medical services, fire, construction, insurance, real-estate, agriculture, oil, gas, transportation, warehousing, food-distribution, surveying, and landscaping.
Some manufacturers design mobile docking stations specially to withstand the rigors of travel; such products may have MIL-STD 810E construction-specifications for vibration and impact.
Mobile docking stations usually come mated to an armature, laptop desk or standard rack in order to provide the ability to position the computer in a vehicle in a safe and ergonomic position. As with all docking stations, a mobile docking station will provide the user with a means to quickly and easily dock and un dock the computer. In addition, some mobile docking-stations provide a security-lock to discourage theft.
Types of mobile docking stations
- Car Mounts are designed for use with most popular automobiles.
- Truck Mounts are designed for use with most popular pickup trucks, vans, SUVs and heavy-duty trucks.
- Cart Mounts and Forklift Mounts are designed to mount notebook, laptop & tablet computers on forklifts and warehouse carts.
Vehicle mount components
Basic components in the design of computer vehicle mounts include:
- Docking station: The actual station or cradle in which the mobile PC rests. These stations may come equipped with additional functionality, such as charging and USB ports.
- Motion attachments: Movable components of a mounting system that attach between the pole or tube and the mount base. These come in a number of varieties, allowing the user to configure their mount's range of motion to desired specifications.
- Mounting base: Attaches the mounting system to the vehicle. This element is commonly composed of rugged materials such as steel. Tunnel Mounts attach to the raised floor area (drive shaft tunnel) between the driver and passenger. Passenger Side Mounts attach to floor on the passenger side of the vehicle. Console mounting brackets attach to an existing vehicle center console. Trunk Mounts provide mounting options for use inside car trunks.
- Poles and tubes: Attachments that allow the user to adjust the length and particular setup of the mount for the particular vehicle style.
Docking systems are shipped in their individual components, requiring the user to install and configure the device.
